详细介绍
特性◥ 100-277VAC输入 ◥ 内置主动式功率因素矫正功能,PF>0.9 ◥ 隔离型,恒流设计(恒流模式) ◥ 100%满载老化测试(智能控制,全封闭,高温老化作业)
◥ 输入接地处理，兼容CLASS1/CLASS2 ◥ 5年产品保修期 ◥ 旋转拨码，4档位拨码调电流，一机多功率
◥ 证书：CUL/UL/FCC
| 产品参数 | |||||||
| 型号/Model | 输出电压 Output Voltage | 输出电流 Output Current | 电流公差 Tol. | 效率 EF | Pf值 PF | 产品净重 Product Net Weight | 产品尺寸 Product Dimensions |
| AGT-B.T516-42W | 20-42V | 400-1000MA | ±40MA | 85% | 0.90 | 201g | 257mm Lx31mm Wx23mm H |
| AGT-B.T111-45W | 27-40V | 700-1100MA | ±44MA | 87% | 0.90 | 250g | 317mm Lx31mm Wx23mm H |
| AGT-B.T210-65W | 27-40V | 1000-1600MA | ±64MA | 87% | 0.90 | 457.8g | 393mm Lx31mm Wx23mm H |
| AGT-B.T310-80W | 27-40V | 1500-2000MA | ±80MA | 87% | 0.90 | 451.5g | 393mm Lx34.5mm Wx27mmH |
| AGT-B.T310-100W | 27-40V | 1900MA-2500MA | ±100MA | 87% | 0.90 | 457.8g | 393mm Lx34.5mm Wx27mmH |
| 交流输入电压范围/Input Voltage | 100-305VAC |
| 交流突入电流(最大)/In-rust Current | 隔离式/Isolated |
| 启动时间/Start Time | 450MS(230VAC满载)/450MS(230VAC Full load) |
| 短路保护/SCP | 打嗝模式,自动恢复/Hiccup mode,Auto-recovery |
| 绝缘强度/Insulation Strength | 3750V |
| 工作环境温度/Operation Temperature | -20℃±60℃ |
| 安规标准/Safety Standard | UL8750 |
| 电磁兼容标准/EMC Standard |
PART15 B |
